Delta DVP Series Slim CPU
The Delta DVP Series Slim CPU is a compact and efficient programmable logic controller (PLC) designed for space-constrained automation applications. Known for its fast execution speed and reliable performance, the Slim CPU is ideal for machine control, packaging, textile, and small automation systems. Its modular design allows for easy expansion with I/O and communication modules, enhancing flexibility. The DVP-S series supports a range of communication protocols including RS-232/485, Modbus, and CANopen, making it suitable for integration into diverse industrial environments. With built-in data logging, PID control, and high-speed counters, the controller delivers excellent processing capabilities. It also features user-friendly programming via Delta’s WPLSoft and ISPSoft platforms. The energy-efficient design and DIN rail mounting further simplify installation and reduce overall system footprint. The Slim CPU is a cost-effective choice for high-performance control in limited space.
| Feature | Specification |
| Model Series | Delta DVP-S (e.g., DVP-SX2, DVP-SS2, DVP-SA2) |
| CPU Type | 32-bit processor |
| Program Capacity | Up to 16k steps (model-dependent) |
| Data Registers | Up to 10k words |
| Execution Speed | 0.24 µs per basic instruction |
| Communication Ports | RS-232, RS-485, USB, CANopen (optional) |
| I/O Points (Max.) | Up to 512 points with expansion modules |
| High-Speed Counters | Up to 100 kHz |
| Programming Software | WPLSoft, ISPSoft |
| Power Supply | 24V DC |
| Mounting | DIN rail |
| Dimensions (approx.) | 90 x 60 x 55 mm (varies by model) |
| Operating Temperature | 0–55°C |
| Certifications | CE, UL, RoHS |
